Your machine: POTATO HARVESTER GT 170 M+S GT170(S/N: 45002062) modify ▸

Subassembly drawing

▸ Selected assembly group:

Selected subassembly

▸
ONION INTAKE WITH ROTOR SHAFT (29 Parts)
▸

Subassembly parts

All items Equipment ex work ()
SUPPORT 1100 WIDE
Quantity in assembly group: 1 Piece / Pos. 1
CLAMPING LEDGE
Quantity in assembly group: 4 Piece / Pos. 2
ANGULAR PLATE
Quantity in assembly group: 2 Piece / Pos. 3
DEFLECTOR R/H
Quantity in assembly group: 1 Piece / Pos. 4
DEFLECTOR L/H
Quantity in assembly group: 1 Piece / Pos. 5
DEFLECTOR R/H
Quantity in assembly group: 1 Piece / Pos. 6
DEFLECTOR L/H
Quantity in assembly group: 1 Piece / Pos. 7
RUBBER PLATE
Quantity in assembly group: 2 Piece / Pos. 8
COACH BOLT M8X25-603-8.8-GAL
Quantity in assembly group: 6 Piece / Pos. 9
DISC R9 DIN440-GAL
Quantity in assembly group: 6 Piece / Pos. 10
CONTACT WASHER FORM M 8-GAL
Quantity in assembly group: 6 Piece / Pos. 11
HEXAGON NUT M8 DIN934-8-GAL
Quantity in assembly group: 6 Piece / Pos. 12
COACH BOLT/SS M8X20-603-8.8-G
Quantity in assembly group: 6 Piece / Pos. 13
COACH BOLT M16X80-DIN603-8.8-G
Quantity in assembly group: 2 Piece / Pos. 14
BRACKET
Quantity in assembly group: 1 Piece / Pos. 15
MH-SCREW M10X30-603-8.8-GAL
Quantity in assembly group: 3 Piece / Pos. 16
WASHER A10,5 DIN125-VERZ
Quantity in assembly group: 3 Piece / Pos. 17
CONTACT WASHER FORM M 10-GAL
Quantity in assembly group: 3 Piece / Pos. 18
HEXAGON NUT M10 DIN934-8-GAL
Quantity in assembly group: 3 Piece / Pos. 19
CHAIN 3/4"X1/2"-ASA60-85R
Quantity in assembly group: 1 Piece / Pos. 20
HOLLOW BOLT
Quantity in assembly group: 1 Piece / Pos. 21
BALL BEARING 6205-2RS
Quantity in assembly group: 1 Piece / Pos. 22
SPROCKET 3/4"-T15
Quantity in assembly group: 1 Piece / Pos. 23
RETAINING RING J 52X2 DIN472
Quantity in assembly group: 1 Piece / Pos. 24
RETAINING RING A 25X1,2 DIN471
Quantity in assembly group: 1 Piece / Pos. 25
CONTACT WASHER FORM M 16-GAL
Quantity in assembly group: 2 Piece / Pos. 26
HEXAGON NUT M16 DIN934-8-GAL
Quantity in assembly group: 2 Piece / Pos. 27
HAULM ROLLER REVERSING KIT
Quantity in assembly group: 1 Piece / Pos. 40
TENSION SPROCKET 3/4"-T15 LONG
Quantity in assembly group: 2 Piece / Pos. 50
