Your machine: POTATO HARVESTER SE75/85-55 SE75-55 ANALOG(S/N: 12502219) modify ▸

Subassembly drawing

▸ Selected assembly group:

Selected subassembly

▸
SIDE PLATFORM NT (34 Parts)
▸

Subassembly parts

All items Equipment ex work ()
PLATFORM L/H
Quantity in assembly group: 1 Piece / Pos. 1
PLATFORM PLATE CENTRE
Quantity in assembly group: 1 Piece / Pos. 2
PLATFORM R/H
Quantity in assembly group: 1 Piece / Pos. 3
INSERT PART
Quantity in assembly group: 1 Piece / Pos. 4
RAIL R/H REAR
Quantity in assembly group: 1 Piece / Pos. 5
RAIL R/H FRONT
Quantity in assembly group: 1 Piece / Pos. 6
LADDER R/H
Quantity in assembly group: 1 Piece / Pos. 7
COVER PLATE REAR
Quantity in assembly group: 1 Piece / Pos. 8
MOVABLE GATE
Quantity in assembly group: 2 Piece / Pos. 9
RIAL R/H FRONT
Quantity in assembly group: 1 Piece / Pos. 10
RIAL L/H FRONT
Quantity in assembly group: 1 Piece / Pos. 11
LADDER L/H
Quantity in assembly group: 1 Piece / Pos. 12
RAIL L/H REAR
Quantity in assembly group: 1 Piece / Pos. 13
BRACKET
Quantity in assembly group: 2 Piece / Pos. 14
MOUNTING
Quantity in assembly group: 1 Piece / Pos. 15
BRACKET F STOP BLOCK
Quantity in assembly group: 2 Piece / Pos. 16
STOP-BLOCK DIN76051 184804(BIG
Quantity in assembly group: 2 Piece / Pos. 17
SHEET
Quantity in assembly group: 1 Piece / Pos. 18
LINING REAR
Quantity in assembly group: 1 Piece / Pos. 19
GAS PRESSURE SPRING 110-150N
Quantity in assembly group: 2 Piece / Pos. 20
BRACKET
Quantity in assembly group: 1 Piece / Pos. 21
PLUG GPN320GL25
Quantity in assembly group: 4 Piece / Pos. 22
CAP
Quantity in assembly group: 2 Piece / Pos. 23
FIXING ANGLE
Quantity in assembly group: 1 Piece / Pos. 24
SPACER TUBE
Quantity in assembly group: 2 Piece / Pos. 25
LINING L/H
Quantity in assembly group: 1 Piece / Pos. 26
WARNING SYMBOL
Quantity in assembly group: 1 Piece / Pos. 27
089.01122 WARNING SYM
Quantity in assembly group: 1 Piece / Pos. 28
089.01266 WARNING SYM
Quantity in assembly group: 1 Piece / Pos. 29
LABEL SE75-55 L/H 2
Quantity in assembly group: 1 Piece / Pos. 30
LABEL SE85-75-55 rear1
Quantity in assembly group: 1 Piece / Pos. 31
LABEL SE75-55 L/H1
Quantity in assembly group: 1 Piece / Pos. 32
LABEL SE85-75-55 L/H3
Quantity in assembly group: 1 Piece / Pos. 33
LABDEL SE85-75-55 L/H 45
Quantity in assembly group: 1 Piece / Pos. 34
