Parts by subassemblies

LADDER

Quantity in assembly group: 1 Piece / Pos. 1

STAGE

Quantity in assembly group: 1 Piece / Pos. 2

PROFILE

Quantity in assembly group: 2 Piece / Pos. 3

LEVER

Quantity in assembly group: 1 Piece / Pos. 4

SHEET-METAL

Quantity in assembly group: 1 Piece / Pos. 5

BRACKET R/H

Quantity in assembly group: 1 Piece / Pos. 6

BRACKET L/H

Quantity in assembly group: 1 Piece / Pos. 7

TUBE

Quantity in assembly group: 1 Piece / Pos. 8

SPACER TUBE

Quantity in assembly group: 2 Piece / Pos. 9

SPACER TUBE

Quantity in assembly group: 8 Piece / Pos. 10

SPACER TUBE

Quantity in assembly group: 1 Piece / Pos. 11

SPACER TUBE

Quantity in assembly group: 1 Piece / Pos. 12

SPACER TUBE

Quantity in assembly group: 2 Piece / Pos. 13

SPACER TUBE

Quantity in assembly group: 2 Piece / Pos. 14

SPACER TUBE

Quantity in assembly group: 5 Piece / Pos. 15

SPACER TUBE

Quantity in assembly group: 3 Piece / Pos. 16

SPACER DISC

Quantity in assembly group: 1 Piece / Pos. 17

TENSION SPRING

Quantity in assembly group: 2 Piece / Pos. 18

TENSION SPRING

Quantity in assembly group: 1 Piece / Pos. 19

GAS STRUT

Quantity in assembly group: 2 Piece / Pos. 20

SNAP CLIP 20,5 796/13

Quantity in assembly group: 1 Piece / Pos. 21

RUBBER BUFFER

Quantity in assembly group: 2 Piece / Pos. 22

STOPPER 75SHORE A

Quantity in assembly group: 2 Piece / Pos. 23

HEX BOLT M8X90-DIN931-8.8-G

Quantity in assembly group: 2 Piece / Pos. 24

HEX BOLT M8X40-DIN931-8.8-G

Quantity in assembly group: 5 Piece / Pos. 25

SET SCREW M8X30-DIN933-8.8-G

Quantity in assembly group: 1 Piece / Pos. 26

HEX BOLT M8X50-DIN931-838-G

Quantity in assembly group: 2 Piece / Pos. 27

HEX BOLT M12X75-DIN931-8.8-G

Quantity in assembly group: 1 Piece / Pos. 28

HHC-SCREW M10X95 DIN931-8.8-GA

Quantity in assembly group: 2 Piece / Pos. 29

HEX BOLT M10X100-DIN931-8.8-G

Quantity in assembly group: 2 Piece / Pos. 30

SET SCREW M8X16-DIN933-8.8-G

Quantity in assembly group: 1 Piece / Pos. 31

EYE BOLT M M8X30 444-8.8-GAL

Quantity in assembly group: 1 Piece / Pos. 32

MH-SCREW M12X45 DIN603-8.8GAL

Quantity in assembly group: 1 Piece / Pos. 33

COACH BOLT M6X20-DIN603-8.8-G

Quantity in assembly group: 2 Piece / Pos. 34

PLAIN WASHER 8.4X20X2 GAL

Quantity in assembly group: 16 Piece / Pos. 35

PLAIN WASHER 13X28X3-GALV

Quantity in assembly group: 2 Piece / Pos. 36

PLAIN WASHER 11X25X2 GAL

Quantity in assembly group: 4 Piece / Pos. 37

WASHER A10,5 DIN125-VERZ

Quantity in assembly group: 6 Piece / Pos. 39

CONTACT WASHER FORM M 6-GAL

Quantity in assembly group: 2 Piece / Pos. 40

CONTACT WASHER FORM M 8-GAL

Quantity in assembly group: 5 Piece / Pos. 41

CONTACT WASHER FORM M 10-GAL

Quantity in assembly group: 2 Piece / Pos. 42

RING NUT M8

Quantity in assembly group: 1 Piece / Pos. 43

NYLOC NUT DIN985-M12-8-GAL

Quantity in assembly group: 1 Piece / Pos. 44

HEXAGON NUT M6 DIN934-8-GAL

Quantity in assembly group: 2 Piece / Pos. 45

NYLOC NUT DIN985-M8-8-GAL

Quantity in assembly group: 2 Piece / Pos. 46

HEXAGON NUT M10 DIN934-8-GAL

Quantity in assembly group: 2 Piece / Pos. 47

HEXAGON NUT M8 DIN934-8-GAL

Quantity in assembly group: 6 Piece / Pos. 48

NYLOC NUT DIN985-M10-8-GAL

Quantity in assembly group: 3 Piece / Pos. 50
