Parts by subassemblies

ANGULAR PLATE

Quantity in assembly group: 1 Piece / Pos. 1

SCRAPER

Quantity in assembly group: 4 Piece / Pos. 2

TORQUE PILLAR

Quantity in assembly group: 1 Piece / Pos. 3

BRACKET

Quantity in assembly group: 1 Piece / Pos. 4

IDLER ROLLER BRACKET R/H

Quantity in assembly group: 1 Piece / Pos. 5

IDLER ROLLER BRACKET L/H

Quantity in assembly group: 1 Piece / Pos. 6

PERFORATED PLATE

Quantity in assembly group: 1 Piece / Pos. 7

CROSS PROFILE LOWER

Quantity in assembly group: 1 Piece / Pos. 8

SHEET-METAL L/H

Quantity in assembly group: 1 Piece / Pos. 9

SHEET-METAL R/H

Quantity in assembly group: 1 Piece / Pos. 10

BRACKET L/H

Quantity in assembly group: 1 Piece / Pos. 11

CLAMPING STRIP

Quantity in assembly group: 2 Piece / Pos. 12

CLAMPING PIECE

Quantity in assembly group: 1 Piece / Pos. 13

SPACER RING

Quantity in assembly group: 2 Piece / Pos. 14

SPACER TUBE

Quantity in assembly group: 1 Piece / Pos. 15

RUBBER

Quantity in assembly group: 2 Piece / Pos. 16

PE-PLATE

Quantity in assembly group: 1 Piece / Pos. 17

PLASTIC COVER

Quantity in assembly group: 1 Piece / Pos. 18

WINDING PROTECTION

Quantity in assembly group: 2 Piece / Pos. 19

SCRAPER SHAFT

Quantity in assembly group: 1 Piece / Pos. 20

SHAFT

Quantity in assembly group: 1 Piece / Pos. 21

SUPPORT ROLLER

Quantity in assembly group: 2 Piece / Pos. 22

PRA PADDLE SHAFT

Quantity in assembly group: 1 Piece / Pos. 23

ROLLER CAP

Quantity in assembly group: 2 Piece / Pos. 24

HYDRAULIC MOTOR MF330 CYL-S

Quantity in assembly group: 1 Piece / Pos. 25

SEAL SET STAND F MF HYD-MOTOR

Quantity in assembly group: 1 Piece / Pos. 26

BEARING YAR 206-2RF/UC206

Quantity in assembly group: 2 Piece / Pos. 27

FLANGE PLATE (PR) PF62/PF206

Quantity in assembly group: 2 Piece / Pos. 28

COACH BOLT M8X16-DIN603-8.8-G

Quantity in assembly group: 10 Piece / Pos. 29

COACH BOLT M10X20-DIN603-8.8-G

Quantity in assembly group: 1 Piece / Pos. 30

MH-SCREW M10X25-603-8.8-GAL

Quantity in assembly group: 1 Piece / Pos. 31

MH-SCREW M10X30-603-8.8-GAL

Quantity in assembly group: 3 Piece / Pos. 32

HEX BOLT M10X40-DIN931-8.8-G

Quantity in assembly group: 2 Piece / Pos. 33

HEX BOLT M10X45-DIN931-8.8-G

Quantity in assembly group: 2 Piece / Pos. 34

HEX BOLT M16X90-DIN931-8.8-G

Quantity in assembly group: 2 Piece / Pos. 35

SET SCREW M12X40-DIN933-8.8-G

Quantity in assembly group: 2 Piece / Pos. 36

HEXAGON NUT M8 DIN934-8-GAL

Quantity in assembly group: 2 Piece / Pos. 37

HEXAGON NUT M10 DIN934-8-GAL

Quantity in assembly group: 2 Piece / Pos. 38

NYLOC NUT DIN985-M10-8-GAL

Quantity in assembly group: 9 Piece / Pos. 39

NYLOC NUT DIN985-M12-8-GAL

Quantity in assembly group: 2 Piece / Pos. 40

HEXAGON NUT M16 DIN934-8-GAL

Quantity in assembly group: 2 Piece / Pos. 41

FEATHER KEY A 8X7X32 DIN 6885

Quantity in assembly group: 1 Piece / Pos. 42

RETAINING RING A 30X1,5 DIN471

Quantity in assembly group: 1 Piece / Pos. 43

CONTACT WASHER FORM M 8-GAL

Quantity in assembly group: 4 Piece / Pos. 44

CONTACT WASHER FORM M 16-GAL

Quantity in assembly group: 2 Piece / Pos. 45

FLAT WASHER M16

Quantity in assembly group: 2 Piece / Pos. 46

WASHER A10,5 DIN125-VERZ

Quantity in assembly group: 4 Piece / Pos. 47

CONTACT WASHER FORM B 10-GAL

Quantity in assembly group: 2 Piece / Pos. 48
