Parts by subassemblies

SIDE PART R/H

Quantity in assembly group: 1 Piece / Pos. 1

SIDE PART L/H

Quantity in assembly group: 1 Piece / Pos. 2

CENTRE PART

Quantity in assembly group: 1 Piece / Pos. 3

CROSS TUBE R/H

Quantity in assembly group: 1 Piece / Pos. 4

CROSS TUBE L/H

Quantity in assembly group: 1 Piece / Pos. 5

CROSS TUBE UPPER

Quantity in assembly group: 1 Piece / Pos. 6

BRACKET

Quantity in assembly group: 2 Piece / Pos. 7

SPACER

Quantity in assembly group: 2 Piece / Pos. 8

CENTRE PART FRONT

Quantity in assembly group: 1 Piece / Pos. 9

TENSION ARM

Quantity in assembly group: 2 Piece / Pos. 10

PLATE

Quantity in assembly group: 2 Piece / Pos. 11

BEAM R/H

Quantity in assembly group: 1 Piece / Pos. 12

TUBE

Quantity in assembly group: 2 Piece / Pos. 13

SPACER TUBE

Quantity in assembly group: 2 Piece / Pos. 14

TENSION SPRING

Quantity in assembly group: 2 Piece / Pos. 15

THREADED ROD M10

Quantity in assembly group: 2 Piece / Pos. 16

HEXAGON NUT M10 DIN934-8-GAL

Quantity in assembly group: 7 Piece / Pos. 17

COTTER PIN 6,3X50 DIN94-GAL

Quantity in assembly group: 2 Piece / Pos. 18

PLAIN WASHER 11X25X2 GAL

Quantity in assembly group: 2 Piece / Pos. 19

DISC A28 DIN125-VERZ

Quantity in assembly group: 2 Piece / Pos. 20

RING NUT M10

Quantity in assembly group: 2 Piece / Pos. 21

BEAM L/H

Quantity in assembly group: 1 Piece / Pos. 22

CSK. ALLEN SCREW M10X20-DIN791

Quantity in assembly group: 20 Piece / Pos. 23

WEAR+TEAR PLATE INNER L/H

Quantity in assembly group: 1 Piece / Pos. 24

CSK. ALLEN SCREW M10X35-DIN791

Quantity in assembly group: 2 Piece / Pos. 25

CONTACT WASHER FORM M 10-GAL

Quantity in assembly group: 1 Piece / Pos. 26

COUNTERSUNK SCREW M10X25 DIN 7

Quantity in assembly group: 4 Piece / Pos. 27

HEX-SCREW M10X45 7991-GAL

Quantity in assembly group: 2 Piece / Pos. 28

WEAR+TEAR PLATE INNER R/H

Quantity in assembly group: 1 Piece / Pos. 29

CHANNEL PLATE OUTER

Quantity in assembly group: 2 Piece / Pos. 30

WEAR+TEAR PLATE OUTSIDE R/H

Quantity in assembly group: 1 Piece / Pos. 31

WEAR+TEAR PLATE OUTSIDE L/H

Quantity in assembly group: 1 Piece / Pos. 32
